ALIENO Pre Phono EXTREMO - In demo in our BIG audio room

ALIENO EXTREME Phono Pre
On demo in our BIG audio room

ALIENO Phono Extremo is an extraordinary tube phono preamplifier, double chassis, for Moving Coil cartridges. It is equipped with three RCA inputs, each of which has independent adjustments to vary the gain (66 – 60 – 54 dB) and the load resistance of the cartridge via blind RCA connectors; these adjustments can be made from the rear panel near each input. The rear panel also houses the output available on RCA and XLR connectors, a switch to enable muting during cable connection operations and the multi-pole connector for the power supply, with Virtual Battery Powered technology, which is in a separate cabinet.
The other adjustments are on the front panel where, starting from the left, there is: an actuator to select the inputs, one to vary the equalization curve between the three available (Decca, RIAA, Columbia) and the last one on the right to switch to mono operation.
All these adjustments can be made during LP playback, as an automatic muting system prevents any possible switching noise from reaching the speakers.
The overall internal impedance of the circuit is less than 250 Ohm, for a perfect match even with very low impedance line preamplifiers (from 2500 Ohm and up).


TECHNICAL SPECIFICATIONS

• Three front-panel switchable RCA inputs; RCA and XLR outputs.
• Three equalizations selectable from the front panel: Decca, RIAA, Columbia.
• Stereo-Mono selector operated from front panel.
• Gain: 66 – 60 – 54 dB, selectable from rear panel.
• Head load: via RCA plugs supplied with 100, 220, 330, 470, 750, 1000 Ohm. Any other resistive load value is available upon simple request.
• Weighted signal-to-noise ratio: >80dB @ 1mV input.
• Harmonic distortion: < 0.05 %.
• Equalization frequency response: +/- 0.1dB.
• Headroom (maximum undistorted output level) over 25 Vrms.
• Output impedance: 250 Ohm, low value ideal for driving pre-line or integrated amplifiers with critical impedances starting from 2500 Ohm.
• Tubes: 12AY7 and ECC83, low noise cascode amplifier stage;
  • E88CC equalization network driver stage;
  • ECC82 additional amplification stage;
  • E88CC buffer stage for driving the outputs.
• Power supply unit with Virtual Battery Powered technology: 240-115 V~ ±10% / 50-60 Hz
• Main fuse: T1Ampere (T2Ampere for 115V).
• Power consumption: approximately 100VA.
• Amplifier section dimensions: L x D x H, cm. 45 x 41 x 22, weight 15 kg.
• Power section dimensions: L x W x H, cm. 33 x 32 x 10, weight 9 kg.
